Sealey Premier Industrial Recovery Winch 5675kg (12500lb) Line Pull 12V

Suitable for industrial recovery and off-road use.

Designed and built with the toughest jobs in mind.

All-metal chassis for long-life and low maintenance.

Motor can easily be rotated 90° to meet various wiring and mounting requirements.

A 6.4hp high power 4.7kW 12V DC motor with a permanent magnet gives first class pulling power.

Innovative 'Double Lock' load-holding brake design provides zero drag when pulling in.

Ergonomic 'lift & turn' free spool clutch.

4-Stage planetary gears.

High quality wire rope feeds through 4-way roller fairlead for even distribution of cable onto drum.

Heavy-duty all-weather housing and IP67 rated motor and gearbox.

3 Year Guarantee*.

Specification:

• Model No RW5675
• Brand: Sealey Premier
• Current Draw: No-Load - 50A, Maximum Load - 390A
• Gear Ratio: 171:1
• Line Pull*: 5675kg(12500lb)
• Line Speed*: No Load - 15m/min, Maximum Load - 1m/min
• Motor Power: 4.7kW(6.4hp)
• Nett Weight: 41kg
• Note: *Performance quoted at first layer of cable onto drum
• Supply: 12V
• Wire Rope Diameter: 9.2mm
• Wire Rope Length: 26m

Product Guarantee: 3 Years
Catalogue Page: Page 1459
