Sealey Industrial High Velocity Orbital Drum Fan 20" 230V

High velocity industrial 3-speed drum fan suitable for movement of huge volumes of air.

Robust unit with heavy-duty gauge steel casing, guard and frame.

Featuring a 360° tilt function allowing for the direction of airflow to be positioned anywhere on a 360° axis.

Carefully balanced and fully guarded blades provide safe operation.

Maximum Airflow: 123.5mᶾ/min(4361cfm).

Fitted with 3-pin plug.

Suitable for industrial, commercial, agricultural, automotive workshop and showroom applications.

Specification:

• Model No HVF20S
• Brand: Sealey
• Current: 0.5A
• Fan Diameter: Ø550mm(20")
• Maximum Airflow: 123.5m?/min(4361cfm)
• Nett Weight: 8.88kg
• Power: 108.6W
• Service Value (SV): 1.1(m³/min)/W
• Standby Power Consumption (P(SB)): 0W
• Fan Sound Power Level (L(WA)): 74dB(A)
• Maximum Air Velocity (c): 1.5m/sec
• Speed Range: 1100-1350rpm
• Speeds: 3
• Supply: 230V
• Maximum Air Velocity (c): 1.5m/sec
• Speed Range: 1100-1350rpm
• Speeds: 3
• Supply: 230V

Product Guarantee: 1 Year
Catalogue Page: Page 1277

Downloadable Files:

• Instructions: View Here
• Parts Diagram: View Here
